Mobile tower crane

Spierings SK598-AT5

The Spierings SK598-AT5 is an 8 tonne mobile tower crane with a 48m jib, supplied with an operator for crane hire or as part of a contract lift.

Maximum capacity: 8 tonnes
Jib length: 48m
Load at jib tip: 1.7 tonnes at 48m

Download the Spierings SK598-AT5 spec sheet

Spierings SK598-AT5 specification sheet
Load charts, working range diagrams, dimensions and axle loads. PDF, 6 pages, 1.1MB.

Download the spec sheet

Specification

Item	Specification
Manufacturer	Spierings
Model	SK598-AT5
Type	Mobile tower crane
Maximum capacity	8 tonnes, at up to 12.8m radius
Jib length	48m maximum
Load at jib tip	1.7 tonnes at 48m on the 7.20m x 7.20m outrigger spread; 1.2 tonnes on 7.20m x 5.65m (jib horizontal)
Jib positions	Horizontal or luffed to 30 degrees
Tower	Hook height 23.8m or 30m with the jib horizontal (height under the jib 25.8m or 32m)
Counterweight	8,700kg full counterweight
Weight and axle loads	60 tonnes total weight
Outriggers	Two positions: 7.20m x 7.20m and 7.20m x 5.65m
Control and safety	All motions with hydraulic proportional controls; 360 degrees continuous slewing; maximum line pull 4,000kg, 2 parts of line; operation allowed up to wind force 8 Beaufort (20m/sec); operating temperature range -15 to 40 degrees C
Ownership	Supplied. Our owned cranes are the electric pick and carry machines

Specifications are taken from the manufacturer published specification sheet for this model and are given as a guide only. Machines vary by build, options and configuration, and figures can change without notice. Nothing on this page forms part of a contract or a lift plan: the crane, its configuration and its load chart are confirmed when we quote and plan your lift.
